The GA Xtreme compressor offers a range of options for both indoor and outdoor use, ensuring reliable operation in even the most demanding environments.
Options

Indoor version
• Air inlet filter and flexibles
• Air intake valve
• Full load/no load regulator
• Long lifetime filtration and separation elements
• Integrated lifting structure
• Heavy-duty air filter
• Air-oil separator
• Compressed air aftercooler and oil cooler
• IPW66 main and fans motors
• ASME based, NR-13 approval
• SmartLink
• Low noise cooling fan for air-cooled units
• Corrosion resistant painting C3H
• IE3 Class F electric motor
• Starters (Star-Delta)

• Pre-mounted electrical cubicles with main breaker
• Elektronikon® unit controller
• Spillage free frame
• Silenced canopy
Outdoor version
• Rain Protection
• Integrated lifting structure
• Structural skid with spillage free frame
• Phase sequence relay
Options
• LV/MV motors
• 50Hz
• Soft starter

Dimensions
TYPE | L | W | H | Weight | ||||
TYPE | mm | inch | mm | inch | mm | inch | kg | lbs |
Indoor | ||||||||
GA 160 Xtreme | 3200 | 1102 | 2042 | 630 | 2414 | 905 | 5300 | 11685 |
GA 200 Xtreme | 3200 | 1102 | 2042 | 630 | 2414 | 905 | 5300 | 11685 |
GA 250 Xtreme | 3200 | 1102 | 2042 | 630 | 2414 | 905 | 5300 | 11685 |
Outdoor | ||||||||
GA 160 Xtreme | 3586 | 142 | 2095 | 83 | 2984 | 118 | 6155 | 13569 |
GA 200 Xtreme | 3586 | 142 | 2095 | 83 | 2984 | 118 | 6155 | 13569 |
GA 250 Xtreme | 3586 | 142 | 2095 | 83 | 2984 | 118 | 6155 | 13569 |
